Archiving SolidWorks Electrical projects

Archiving SolidWorks Electrical project to Project.TEWZIP

  • Open Electrical and its Project manager.
  • Then there will be asked; Do you want to update your Electrical drawings.
      • You should always update your drawings when archiving project. in this case, the project pages are up to date when the archiving is done.


  • SolidWorks Electrical starts a SaveAs command and ask you where to save the project.
      • TEWZIP file. → Save the file to a location of your choice.
  • SolidWorks starts to archiving. → SolidWorks stores all the data, what is related to the
  • mceclip5.png
  •  The project is stored now. → File looks like this.mceclip6.png
